Enhance your Snorkel with accessory packages designed for various applications. All Snorkel accessory packages are factory installed to meet the highest quality standards.
Protecting against debris and other harmful objects, the Extreme Environment Package keeps machines running smoothly in rough terrain. The sandblast protection kit shields all critical moving parts in protective nylon covers. Class-leading boom wiper seals keep debris out of boom sections for a long working life. Sandblast protection kit Boom wiper seals Platform control box cover
Designed by Snorkel’s in-house engineering team, the Snorkel guard system features a spring-loaded rail mounted above the platform controls, which cuts-out machine operations when pressure is applied. If the operator is able, they can restore power using the override switch in the platform. Alternatively, the ground controls can be used to lower the platform. Snorkel Guard™ is fitted as standard on all new build Snorkel boom lifts. A retrofit kit is available for most Snorkel booms in the field. Retofit kit includes Snorkel Guard™ rail Mounting brackets Fixings Installation guide NOTE: Snorkel Guard™ retrofit kits are painted Snorkel orange as standard. If special colors are required, please request this at the time of ordering. Download Snorkel Guard brochure: 中文 Deutsch English Français 日本語 Español
Equipped for tunneling work, the Tunnel Package outfits the machine with durable 3.5kW hydraulic generator, along with a diesel oxidation catalyst (DOC) and a spark arrestor to reduce emissions. For a long working life, an engine block heater maintains battery life and an air pre-cleaner extends filter life. Bright LED work lights also provide visibility in low light within tunnels. 3.5kW hydraulic generator Work light package Driving light scrubber Diesel scrubber Spark arrestor Engine block heater & charger Air pre-cleaner
Equipped with a 3500 psi pressure washer package, operators can wash large surfaces. Large water tanks mounted on either side of the chassis hold up to 400 gallons of water with a basket-mounted hose reel for maximum wand movement and maneuverability in confined spaces. 10kW generator Onboard 3500 psi pressure washer Two 200-gallon water tanks Basket mounted hose reel with wand Limited non-continuous 360 degree rotation
For safe operation when working on or around aircraft, the Aircraft Bumpguard System helps provide all-around protection. A pressure-sensitive switch within the rail padding will shut off machine operations if contact is made from any direction. Foam padded platform rail weldments Switch tape between the platform rails and the foam padding Extension deck interrupt switch Override control to regain full control
In addition to a block heater and hydraulic warm-up kit, the Extreme Cold Weather Package provides even more protection in frigid conditions. An electric heat pad insulates the battery to allow for a quick start, and synthetic oil helps prevent engine wear for long-lasting performance. Cold Weather package plus Battery blanket Synthetic oil
Providing visibility for working in low light, the Lights Package includes heavy-duty, low-energy LED work lights. Bright, long-lasting work lights are mounted to the platform, control panel and counterweight for easy driving and operating any time of day. Platform lights Control panel Driving headlights
Fully loaded and ready for welding, the 12k Generator Welder Package features a durable, hydraulically driven generator and heavy-duty Lincoln V275-5 welder. Lincoln V275-5 welder Hydraulic 208VAC 3-ph generator
To enhance performance in low temperatures, the Cold Weather Package includes an electric block heater that preheats engine coolant and a hydraulic warm-up kit to circulate and heat oil. Block heater Hydraulic warm-up kit
U shape brackets mounted on platform Ratchet straps for securing pipe Lift pipes up to elevation that are 6” diameter, 10’ length and up to 150 lbs max weight
Available in 2.5, 3.5 and 10kW, customizable power outlets make for easy work at height. Also conveniently included in the Generator Package are a platform welder bracket and hydraulic oil cooler for various applications. 10kW 208VAC 3-ph, 60Hz outlet, or 3.5kW 208VAC 3-ph, 60Hz outlet, or 2.5kW 120VAC 1-ph, 60Hz outlet Platform welder bracket Hydraulic oil cooler (below 50 ft./15.2m)
An enhanced bumpguard system features rubberized liner for added safety while working on and around aircrafts. The Deluxe Aircraft Package includes a sensor-activated bumpguard with enhanced padding, front-mounted tow kit for easy transportation and fall arrest protection. Components are also painted in safety yellow to enhance visibility. Aircraft package plus Enhanced padded bumpguard
Easily move machines around a jobsite with a complete Tow Kit. Attach the included safety chain to the tow bar, and use the float valve and steering link to easily steer. Tow bar Float valve Chain
Battery-powered electric motor Lever-actuated operation Precise positioning without tools
Designed for safe working with glass, the Glazier Package features easy-to-install attachments. Rubber-lined, steel tray hooks with snap pins make for easy mounting. Secure fragile materials with enhanced platform rail padding and heavy-duty straps. All components can be detached and placed in the included storage box when not in use. Two trays with keeper pins Platform rail padding Straps with protectors Storage box
Designed for the utility industry, the Utility Package, which is available on boom lifts, includes an aluminum platform with swing gate and Snorkel Guard, two grounding loops and a 2kW AC generator. Conveniently located on either side of the chassis are two copper grounding loops to ground the machine electrically. Providing power to platform are a Kubota engine and 2kW generator. 5 ft./1.5m aluminum platform with swing gate (500 lbs./227kg capacity) Grounding loops 2kW AC generator
Designed to provide protection against damage when working on or around aircraft, the bumpguard system will shut off machine operations if contact is made. The Aircraft Package also includes an easy access swing gate and a tow kit for use around the airport. Bumpguard system Tow kit Swing gate Fall arrest protection
