Snorkel A46JRTE
52 ft 11 in Working Height
500 lbs Platform Capacity
16,620 lbs Weight

A46JRTE

The electric version of the Snorkel A46JRT articulating boom lift, the A46JRTE offers clean performance and quiet operation from lithium-ion batteries. This fully electric model delivers the same rough terrain capability from battery power. Designed to be versatile, the A46JRTE has superb maneuverability and can work indoors.

Specifications
Max. working height
52 ft 11 in
Max. platform height
46 ft 11 in
Max. horizontal reach
24 ft 11 in
Clearance height at max. outreach
25 ft 2 in
Platform size
39 in x 72 in
Chassis width
6 ft 10 in
Overall length
18 ft 8 in
Stowed height
7 ft 2 in
Ground clearance
13 in
Platform capacity (SWL)
500 lbs
Max. drive height
46 ft 11 in
Max. wind speed
28 mph
Max. drive speed (elevated)
0.8 mph
Max. drive speed (stowed)
4.25 mph
Raise / lower time
101/98 sec
Gradeability
45%
Jib length
5 ft
Jib arc
140º
Platform rotation
160º
Superstructure rotation
360º non-continuous
Tailswing
0 in
Inside turning radius
2 ft 8 in
Outside turning radius
10 ft 5 in
Tires
foam filled lug 355/55D625
Controls
proportional
Drive system
4 wheel drive
Power source
333Ah Li-ion batteries with integrated BMS
Operating Temperature
(-)77°F to (+)140°F
Charger
High frequency smart on-board 50A battery charger
Motor
AC electric motor
Weight
16,620 lbs

Specifications subject to change without notice. The equipment hereunder have been subject to limited testing, and any performance specifications and representations are the result of limited testing. Photos and diagrams are shown for illustrative purposes only. Snorkel makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its equipment for any particular purpose. It is the Buyer’s responsibility to independently determine suitability of any equipment or parts, and to test and verify the same. Refer to appropriate Snorkel operator’s manual for detailed instructions on the proper use and maintenance.

Last Updated
12/2021

Standard Features

  • Three lithium-ion battery systems 333Ah
  • Snorkel Guard™ secondary guarding system
  • Multi-function proportional controls
  • Oscillating front axle
  • Zero tailswing
  • Tri-entry platform
  • Non-marking foam filled tires
  • Power line to platform
  • Hour meter & on-board diagnostics display
  • Tilt alarm
  • Horn
  • Drive motion alarm
  • Flashing amber light
  • Platform overload system
  • 2000 charging cycles/2 year** lithium battery warranty
  • 2 year parts & labor, 5 year structural warranty

Options

  • Special paint colors
  • Airline to platform
  • Pneumatic tires
  • 5’ aluminum platform with swing gate
  • Additional 111Ah battery system
  • Aircraft package
  • Deluxe aircraft package
  • Extreme environmental package
  • Glazier package
  • Light package
  • Utility package
  • Tool tray
  • Pipe rack
  • Environmental hydraulic oil
  • Snorkel OnSite™ telematics
  • Personal fall arrest system

Working Envelope

Snorkel A46JRTE Working Envelope Imp
